Others Product

Featured by classy design, superb light-weight and compact size have been successfullypulling PD30 SERIES on hot selling since it was launched early in 2020.

With appropriate and professional optically optimized, the beam profile of each lasercolourbetween R/G/B is nearly a perfect spot, and all beams match each other in shape,beam size and divergence, ensuring all the mixed colours are overlapped and without anystray beams around them.

We hope this nicely built gear will continuously help our valued customers succeed.

Product Parameters

Video Presentation

Data Download

Specification

ModelsWP100-RGB
Source | Type:Semiconductor diode | Full-colour RGB laser projector
Suitability:outdoor laser displays [atmospheric, abstract, text, animations]
Beam Size@Aperture[mm]
Divergence(full angle)0.95mrad
System controlFB4-MAX
Scanning SystemOPT30PB 20Kpps@8°,MAX±20°
Wavelength [nm]R/638 G/520 B/445
Laser Power [mW]27300mW / 35000mW / 36000mW
Guaranteed opt. output [mW]80W
Modulation [kHz]100 | analogue
Power Supply100~240V 50~60Hz
Power Consumption [W]
Weight [kg]74.34Kg
Size [WxHxD, mm]581*780*467.5mm
Cooling:Heatsink+TEC Cooling+Casting Aluminum Housing+Fans (at bottom)
Packaging:Road case
Operation temperature [°C]:minus 20℃ to 40℃
